TBSB Economy Tee Base Stuffing Box
Combines the stuffing box and pumping tee in one body — eliminating one wellhead connection. Integral 1" bleeder port. Available with 2" or 3" LP side outlets depending on bottom connection size. Convertible to Inverted Tee Base (IVTBSB).
Quick Specifications
BTM THREAD 2", 2-½", 3"
BOTTOM CONNECTION Female
HEIGHT 16"
WEIGHT (2") 33 lbs.
WEIGHT (2-½") 37 lbs.
WEIGHT (3") 42 lbs.
SIDE OUTLETS (2" BTM) 2" LP
SIDE OUTLETS (2-½"/3" BTM) 3" LP
TOP CONES REQUIRED 4
BOTTOM CONES REQUIRED 1
ORG / ELUG™ Optional
INVERTED CONVERSION Available (IVTBSB)
Key Features
WHY THE SPSB
Eliminates One Connection
Combines stuffing box and pumping tee in one body — removing one threaded wellhead connection. Fewer joints means fewer potential leak points and simpler installation.
Convertible to Inverted Style
The TBSB can be converted to the Inverted Tee Base (IVTBSB) in the field — providing a lower-profile alternative without replacing the complete assembly.
1" Bleeder Port Included
Integral 1" bleeder port is standard — no additional fittings required. Side outlet size automatically matched to bottom connection size.
Correct Outlet for Your Size
Misalignment Tolerance
ECSS™ Compatible
Accepts E-LUG™ Environmental Lube Upper Gland for secondary sealing and environmental compliance. Connects to ECSS™ Environmental Shutdown Switch.
Full Specifications
BTM THREAD 2", 2-½", 3"
BOTTOM CONNECTION Female
HEIGHT 16"
WEIGHT (2") 33 lbs.
WEIGHT (2-½") 37 lbs.
WEIGHT (3") 42 lbs.
SIDE OUTLETS (2" BTM) 2" LP
SIDE OUTLETS (2-½"/3" BTM) 3" LP
TOP CONES REQUIRED 4
BOTTOM CONES REQUIRED 1
ORG / ELUG™ Optional
INVERTED CONVERSION Available (IVTBSB)
Product Notes
- Combines stuffing box and pumping tee — eliminates one threaded wellhead connection
- 1" bleeder port included
- Side outlets: 2" LP with 2" bottom; 3" LP with 2-½" or 3" bottom
- Distinctive misaligning feature reduces installation alignment requirements
- Grease zerk standard
- Optional ELUG™ or S-ORG™ upper gland
- Convertible to Inverted Tee Base (IVTBSB)
Packing Options
Select the packing compound best suited for your well fluid chemistry, temperature, and operating conditions.
SOFT
SBR
HSN
HNBR - H₂S
SB SILICONE
HARD
SBR
HIGH TEMP
NBR - STEAM
SUPER DOME™
NBR/HNBR - PREMIER
TEFLON
SBR
KB™
BRASS FILLED
SUPER LIFE™ 575
POLYMER - PREMIER
Compatible Accessories
WSI accessories that install directly on the TBSB.
Environmental Lube Upper Gland
Secondary seal above any Classic style stuffing box. Connects to ECSS™ Environmental Shutdown Switch and anti-pollution tank. Rod sizes 1"–1-¾".
Standard Oil Reservoir Gland
1 quart oil reservoir for pumping/flowing wells. Split cone wiper controls oil film on rod. Connects to ECSS™ shutdown switch. Fits any Classic style stuffing box including SPSB.
Polished Rod Lubricator
1 quart reservoir reduces friction heat between polished rod and packing — extending packing life significantly. Especially important for wells on timer controls.
Related Stuffing Boxes
Other WSI stuffing box models that may better suit your pressure requirements, well conditions, or installation constraints.
DPSB Economy Double Pack
